Spec My PTAC

Cooling Type

Cooler

Heat Pump

Model Type

Standard Efficiency	High Efficiency
DigiAir	Dry

Refrigerant

R32

R410A

Nominal Cooling Capacity

7,000 BTU/h	12,000 BTU/h	17,000 BTU/h
9,000 BTU/h	15,000 BTU/h

Voltage

230/208 Volt

265 Volt

Electric Heat Capacity

None	2.5 KW	5.0 KW
1.5 KW	3.5 KW

Factory Installed Options (Up to 3)

No Options	Lighting Control
Corrosion Protection	Hydronic Heat
DigiAir Heater Kit
Power Door Power Vent

Sleeves

None
Standard Wall Sleeve	Seacoast Protected
Heavy Sound Isolation	Internal Drain
Extra Deep Collapsible
Sleeve Depth:	Sleeve Depth:

Chassis Accessories

You must select a hydronic heat kit.

None	Hydronic Steam Heat Kit
Condenser Baffle Kit	Leveling Legs
Condensate Drain Kit	Main Duct Kit
Curtain Guards
Extension Duct
Hydronic Water Heat Kit

EMS/Wireless Thermostat

None

Occupancy Sensor

Wireless Thermostat

Outdoor Grilles

None	Aluminum Architectural Grille - Dark Bronze
Aluminum Architectural Grille - Amana White	Aluminum Architectural Grille - Aluminum
Aluminum Architectural Grille - Stonewood Beige	Aluminum Architectural Grille - Custom Color
Aluminum Architectural Grille - Quiet White	Polymer Architectural Grille - Dark Bronze
Polymer Architectural Grille - Amana White	Polymer Architectural Grille - Stonewood Beige
Polymer Architectural Grille - Quiet White	Standard Grille - Quiet White
Standard Grille - Aluminum

Electrical Accessories

None	Low Voltage Wire Harness Kit
230/208V 15/20A Sub-Base Kit	15A Circuit Breaker Kit
230/208V 30A Sub-Base Kit	20A Circuit Breaker Kit
265V 15/20A Sub-Base Kit	30A Circuit Breaker Kit
265V 25A Sub-Base Kit	265V Electrical Switch Kit
230/208V Electrical Switch Kit	Hardwire Kit

Wired Thermostats

None	Hardwired 2 Speed Fan Auto Changeover / Programmable
Hardwired 2 Speed Fan

Wireless Thermostats

Eden Energy Management Thermostat

Basic Wireless Thermostat

Description:

Hover over selections for more information.
